LMW - Carding Machine
An infographic style rendering to explain the workings of the Carding machine for Lakshmi Machine Works.
Caterpillar Engine
A cut section view of the Caterpillar Engine showing the Stroke cycles.
Concrete Cooling Systems - KTI
An aerial view of the full stack of the Concrete Cooling System designed by KTI Plersch, Germany.
LVS 25 - LMW
A front perspective of the LVS 25, a vertical CNC lathe from Lakshmi Machine Works
LVS 25 - LMW
A front perspective of the LVS 25, a vertical CNC lathe from Lakshmi Machine Works
Ring Frame - LMW
Perspective view showing the full length of the Ring Frame from Lakshmi Machine Works
LH 45 - LMW
A front perspective view of the LH 45, a horizontal CNC lathe from Lakshmi Machine Works
LH 45 - LMW
Perspective view of the LH 45, showing the components at the back
LH 45 - LMW
Perspective view of the LH 45, cut section style, showing the tool changer, the bed, the spindle and the ball screws.
Ring Frame - LMW
Perspective view showing the full length of the Ring Frame from Lakshmi Machine Works
